OCS2660-H08-C
2U storage chassis with SuperMicro motherboard compatibility.
- 8 × front 3.5-inch hot-swap bays, also supporting 2.5-inch drives
- EEB / CEB / ATX / Micro-ATX form factor support
- 4 × 8038 hot-swap cooling fans
- Redundant CRPS PSU options: 550W / 800W / 1300W
Please include your product model, required quantity, and any customization needs.
01 / OVERVIEW
Product overview
The OCS2660-H08-C is a high-quality 2U 8-bay storage server chassis, engineered for enterprise-level storage applications, cloud infrastructure, and edge computing environments. Built with precision using Taiwan Zhonggang SGCC 1.0mm steel, it ensures excellent structural integrity and long-term durability.
This chassis offers full compatibility with SuperMicro motherboards, including EEB (12×13″), CEB, ATX, and Micro ATX standards—providing maximum flexibility for a variety of server configurations.
The front panel supports 8 × 3.5″ hot-swappable HDDs (2.5″ compatible), plus internal support for additional 2.5″ drives and optional NVMe OS modules. Rear PCI-e expansion supports one low-profile GPU card, enabling light AI or parallel processing workloads within a compact form factor.
Enhanced with CRPS redundant power supply support (550W / 800W / 1300W 80PLUS Platinum), 4 × 8038 hot-swappable cooling fans, and customizable components (front panel, rack rails, branding, etc.), the OCS2660-H08-C is an ideal choice for high-availability storage servers.
02 / SPECIFICATIONS
Technical specifications
Please confirm the selected configuration and included components with our team before ordering.
| Specification | |
| Chassis Model | OCS2660-H08-C |
| Dimensions | D660*W438.4*H88mm |
| Materials | Taiwan Zhonggang SGCC 1.0mm |
| Front Panel | Power switch/RESET button, power/hard drive/network/alarm/status indicators/lights. Supports two USB 3.0 ports and one COM port (optional). |
| Storage Support | Front panel supports 8 × 3.5" hot-swappable hard drive bays (2.5" compatible), 2 × 3.5"/2.5" internal hard drives. Rear panel supports 2 × 2.5" internal hard drives and 2 × 2.5" NVMe hot-swappable OS modules (optional). |
| PCI-e Expansion | Supports 7 × low-profile PCI-e expansion slots. |
| System Fan | Integrated shock absorption/standard configuration with 4 × 8038 hot-swappable system cooling fan modules (silent version/PWM, high-quality fans with a 50,000-hour warranty). |
| Backplane | Supports eight SAS/STA 12Gbps direct-connect backplanes. |
| Power Supply | Redundant power supplies support 550W/800W/1300W 80PLUS Platinum Series CRPS 1+1 high-efficiency redundant power supplies. Single power supply supports 600W 80PLUS single-cell high-efficiency power supplies (single-cell bracket optional). |
| Motherboard | Supports EEB (12x13), CEB (12x10.5), ATX (12x9.5), and Micro ATX standard motherboards. |
| Environmental Specifications | 10°C to 35°C operating temperature, 8% to 90% operating humidity (non-condensing) -40°C to 70°C storage temperature, 5% to 95% storage humidity (non-condensing) |
| Optional | |
| Items | Description |
| HDD backplane | 12 x SAS/STA 12Gbps direct-connect backplanes |
| Power supplies | 1+1 redundant: 550W/800W/1300W original power supplies (Platinum) (optional); single power supply: 600W 80PLUS power supply. |
| 2x 2.5" HDD OS module | 2 × 2.5" hot-swappable hard drive enclosures; optional SATA direct-connect backplane + NVME backplane/built-in 2 × 2.5" hard drive brackets |
| Rear fan module | N/A |
| HDD data cable | Customizable data cable lengths available |
| Power cable | 3C-certified high-quality server power cables |
| Chassis front panel | Customizable 2U front panel |
| Rack rails | 1. 2U support-type rack rails; 2. 2U tool-free quick-release ball bearing fully removable rails |
| Customization | Customizable logos, enclosure color, and packaging materials available. |
